Product name : Plastic Welding Extruder
Size : SWT-NS600F
Welding Range : 3.0mm-4.0mm
Package QTY : 1 pcs alloy box
G.W : 13kgs
N.W : 6KGS
MEAS :
 Enlarge Image                   Back
←[Previous Product]              [Next Product]→


Details:

Hand held Plastic Extrusion Welder-- PE hand extruder gun
1.This series of welding machine is powerful with high welding speed and good welding quality.
2.It is available for welding PE, PVDF, PVC, PP and other hot melt materials.
3.It is the first one to have a digital display control, 360 degree rotating welding head,
the motor cold start protection, independent heating of welding rod and membrane material and other functions in China.
Voltage 220 V ± 5%
Frequency 50/60Hz
Extruding Power 1100W
Hot Air Power 3400W
Welding Rod Heating Power 800W
Air Temp 20-600°c Adjustable
Extruding Temp 200-300°c Adjustable
Welding Speed  2.0-2.5Kg/h
Welding Rod DIA 3.0mm-4.0mm
Weight 7.5Kg
Application
PE welding rod hand extruder welding tool

Features
1.Vinyl Weld Extruder Welder Machine
2.Adjustable preheat extension
3.Solid, durable construction, easy operation
4.Suitable for welding PE, PP, PVDF
